Get Perfect Audio with an Extended Speakerphone

The VC520 Pro2 offers balanced and steady audio performance. As the first conferencing system in the industry to deliver a daisy-chain function, the VC520 Pro2 supports either up to two expansion speakerphones or a full duplex microphone array. The inventive speakerphone makes the VC520 Pro2 a flexible option for fit mid-to-large conference rooms.

Note:
  • Expansion speakerphones and microphones cannot be added together.
  • The standard speakerphone cannot be applied as an expansion speakerphone.

VC520 Pro2
VC520 Pro2
VC520 Pro2
Configuration
  • Max. Cable length of each combination is 40 meters, from the Camera.
VC520 Pro2
VC520 Pro2

Support Video and Audio with One USB Cable

Installing the VC520 Pro2 is super easy. All you need to get set up for a call is a single USB cable. This direct connection not only saves time but also keeps your meeting table tidy and organized. Simplify your setup process and decrease installation costs with the VC520 Pro2.

Spot Every Detail with an 24X* Total Zoom

Present products in extreme clarity and demonstrate every detail with an 24X* total zoom. The VC520 Pro2 also maximizes team collaboration with smoother video imaging than ever at up to 1080p, 60fps quality.

*Please use PTZApp 2 to set up 24X zoom.

VC520 Pro2

Improve Meeting Safety & Efficiency with SmartFrame

AVer developed an advanced SmartFrame function that conforms to the latest trends. Equipped with this upgraded auto-framing feature, the VC520 Pro2 can detect and frame meeting participants even when they wear masks or present facial profiles from up to 7 meters away. The VC520 Pro2 cuts through triviality and greatly improves conferencing efficiency.
Auto Framing Preset Framing

VC520 Pro2
VC520 Pro2

Livestream Videos Anytime, Anywhere

Share your real-time happenings to viewers over the internet. With H.264 RTSP/RTMP support, the VC520 Pro2 offers stable livestreaming to your favorite channel in 1080p at 60pfs. Deliver first-hand information to your audience and address the latest news whenever and wherever you like.

Keep Natural Clarity in Any Light Conditions

There’s no need to worry about lighting anymore! The Sony sensor embedded in the VC520 Pro2 enables True WDR up to 120dB. Effortlessly control the light values of pixels and display constant clarity on the screen.

VC520 Pro2

Hardware Spec

  • 1Available with VC520 Pro2 Speakerphone set
  • 2USB 3.1 Type-B
  • 3RS232 in/out
  • 4DC 12V
  • 5LAN for IP streaming / remote access
  • 1Mute/Unmute
  • 2Phone input
  • 3Make/Answer call
  • 4Volume up
  • 5LED status indicator
  • 6Volume down
  • 7Hang up call
  • 8Daisy-chain up to 3 speakerphones or 4 microphones
  • 9Phone in
  • 10Line out
  • 11Available with VC520 Pro2 camera set

AVerBravo

VC520 Pro2 vs. VC520 Pro
Model VC520 Pro2 VC520 Pro
Camera
Zoom Ratio 12X Optical Zoom (18X Total Zoom) 12X Optical Zoom (18X Total Zoom)
Resolution 1080p 1080p
FOV 84.5° 82°
Frame Rate USB: 1080p/60fps USB: 1080p/60fps
Video Formats M-JPEG/YUV/H.264 M-JPEG/YUV/H.264
Movement PTZ PTZ
Pan 340° (±170°) 340° (±170°)
Tilt 120° 120°
Preset 10 on remote (128 via RS232) 10 on remote (128 via RS232)
Far-Site Control Yes (only applicable to Skype for Business) Yes (only applicable to Skype for Business)
Speakerphone
Expansion Solutions Up to 3 speakerphones or 4 microphones Up to 3 speakerphones or 4 microphones
Speakerphone I/O Phone in/Line out Phone in/Line out
Advanced Features
SmartFrame Yes (Auto framing, Preset framing) Yes (Auto Framing)
WDR True WDR True WDR
IP Streaming Yes (RTSP/RTMP) Yes (RTSP/RTMP)
RS232 Yes (RS232 in/out) Yes (RS232 in/out)
Certifications & Awards
  • Zoom Certified
  • ClickShare Conference label Certified alliance def
  • 2021 Globee Award
